HH-9460DP
Two-part toughened epoxy with ultra-long working time, high peel & impact resistance
Bond carbon fiber sports gear (fishing rods, bike frames, sleds); general assembly for metal, plastic, rubber, glass, ceramic, leather, fiber & electronic parts; secure wiring boxes, cable sleeves and rivet weld joints needing high shear strength.
A:Black B:Amber
Color
A:45000-65000 B:5000-8000
Viscosity(mPa⋅s)
-50-130
Temperature(℃)
Description
SUITIT HH-9460DP is industrial two-component structural epoxy made of modified bisphenol A resin and modified amine hardener. It delivers excellent solvent resistance, stable electrical insulation, superior peel, shear and shock resistance, with ultra-long open time for large-area and complex assembly operations.
Features
- Dual curing: ambient temperature or accelerated heat curing
- Low-odor, solvent-free non-toxic formula
- Stable outstanding electrical insulation performance
- Ultra-high bonding strength, excellent anti-impact toughness
- Wide service temperature range (-50~130℃), long-term stable below 100℃
- Extra long 1–2 hour working time, convenient for large & complex part alignment
Specification
Curing Schedule
- Working Time (25℃): 1–2 h
- Full Cure: 24h @25℃; 3h @80℃
Cured Mechanical Properties
- Shore D Hardness: 65–75
- Tensile Strength: ≥25 MPa
- Elongation at Break: ≥10%
- Steel Shear Strength: ≥25 MPa
- Sandblasted & Anodized Aluminum Shear Strength: ≥25 MPa
- Water Absorption (25℃, 24h): <0.3%
Storage & Packaging
- Storage Condition: Sealed original packaging at ≤25℃
- Shelf Life: 12 months from production date
- Standard Sizes: 50ml, 400ml cartridges; custom specifications available
